IndraDrive is the most recent Indramat drive system, and it provides all of the versatility, customization, and reliability you expect from Indramat. While these drives rarely fail, they may need support from time to time. Your system generates a fault code, or error code diagnostic message, when something isn’t working correctly. Here’s a list of Indramat error codes in the F2000 range.
F2000’s
- F2003 Motion step skipped
- F2004 Error in motion profile
- F2005 Cam shaft invalid
- F2006 MMC was removed
- F2007 Switching to non-initialized operating mode
- F2008 RL The motor type has changed
- F2009 PL Load parameter default values
- F2010 Error when initializing digital I/O
- F2011 PLC-Error nr. 1
- F2012 PLC-Error nr. 2
- F2013 PLC – Error nr. 3
- F2014 PLC – Error nr. 4
- F2018 Device overtemperature shutdown
- F2019 Motor overtemperature shutdown
- F2021 Motor temperature monitor defective
- F2022 Device temperature monitor defective
- F2025 Drive not ready for Control
- F2026 Undervoltage in power section
- F2027 Excessive oscillation in DC bus
- F2028 Excessive deviation
- F2031 Encoder 1 error: signal amplitude incorrect
- F2032 Validation error during commutation fine adjust
- F2033 External power supply X10 error
- F2036 Excessive position feedback difference
- F2037 Excessive position command difference
- F2039 Maximum acceleration exceeded
- F2040 Device overtemperature 2 shutdown
- F2042 Encoder 2: encoder signals incorrect
- F2043 Measuring encoder: encoder signals incorrect
- F2044 External power supply X15 error
- F2048 Low battery voltage
- F2050 Overflow of target position preset memory
- F2051 No sequential block in target position preset memory
- F2053 Incr. encoder emulator: pulse frequency too high
- F2054 Incr. encoder emulator: hardware fault
- F2055 External power supply X31/X32 error
- F2057 Target position out of travel range
- F2058 Internal overflow by positioning input
- F2059 Incorrect command value direction when positioning
- F2063 Internal overflow master axis generator
- F2064 Incorrect cmd value direction master axis generator
- F2067 Synchronization to master communication incorrect
- F2069 Error when releasing the motor holding brake
- F2074 Actual pos. value 1 outside absolute encoder window
- F2075 Actual pos. value 2 outside absolute encoder window
- F2076 Actual pos. value 3 outside absolute encoder window
- F2077 Current measurement trim wrong
- F2086 Error supply module
- F2087 Module group communication error
F2100’s
- F2100 Incorrect access to command value memory
- F2101 It was impossible to address MMC
- F2102 It was impossible to address I2C memory
- F2103 It was impossible to address EnDat memory
- F2104 Commutation offset invalid
- F2105 It was impossible to address Hiperface memory
- F2110 Error in non-cyclical data communic. of power section
- F2120 MMC: defective or missing, replace
- F2121 MMC: incorrect data or file, create correctly
- F2122 MMC: incorrect IBF file, correct it
- F2123 Retain data backup impossible
- F2124 MMC: saving too slowly, replace
- F2130 Error comfort control panel
- F2140 CCD slave error
- F2150 MLD motion function block error
- F2174 Loss of motor encoder reference
- F2175 Loss of optional encoder reference
- F2176 Loss of measuring encoder reference
- F2177 Modulo limitation error of motor encoder
- F2178 Modulo limitation error of optional encoder
- F2179 Modulo limitation error of measuring encoder
- F2190 Incorrect Ethernet configuration
F2200’s
- F2260 Command current limit shutoff
- F2270 Analog input 1 or 2, wire break
F2800’s
- F2802 PLL is not synchronized
- F2814 Undervoltage in mains
- F2815 Overvoltage in mains
- F2816 Softstart fault power supply unit
- F2817 Overvoltage in power section
- F2818 Phase failure
- F2819 Mains failure
- F2820 Braking resistor overload
- F2821 Error in control of braking resistor
- F2825 Switch-on threshold braking resistor too low
- F2833 Ground fault in motor line
- F2834 Contactor control error
- F2835 Mains contactor wiring error
- F2836 DC bus balancing monitor error
- F2837 Contactor monitoring error
- F2840 Error supply shutdown
- F2860 Overcurrent in mains-side power section
- F2890 Invalid device code
- F2891 Incorrect interrupt timing
- F2892 Hardware variant not supported
What do you do if you see an F2000 Indramat error code?
You might be able to fix the problem in-house. However, problems with your Indramat motion control system may require professional service. Either way, contact us immediately whenever you see an Indramat error code. We will walk you through troubleshooting over the phone, and we have charter flights available when you need on-site support fast.
Call 479-422-0390 or contact us today for immediate Indramat support.
